Product Overview:
The Y-strainer is an indispensable device in pipeline systems for conveying media.It is typically installed at the inlet end of pressure reducing valves,pressure relief valves, constant level valves,or other equipment,to remove impurities from the medium and ensure the normal operation of valves and equipment.
Main Parts Materials:
| Body Material | Filter Screen | Total Open Area of Screen |
|---|---|---|
|
Gray Cast Iron,Ductile Cast Iron, Carbon Steel |
Stainless Steel | 3~4 DN |
Parameters:
| Model | Connection Type |
Nominal Pressure PN (MPa) |
Hydrostatic Test Pressure (MPa) |
Working Pressure (MPa) |
|||
|---|---|---|---|---|---|---|---|
| GL41H-10 | Flanged | 1.0 | 1.1 | 1.0 | |||
| SY4P-16 | Flanged | 1.6 | 1.76 | 1.6 | |||
| SY4P-25 | Flanged | 2.5 | 2.75 | 2.5 | |||
Main External Dimensions:
| Nominal Diameter | External Dimensions | ||||||
|---|---|---|---|---|---|---|---|
| L | H | H1 | |||||
| 65 | 250 | 198 | 270 | ||||
| 80 | 280 | 210 | 295 | ||||
| 100 | 350 | 250 | 344 | ||||
| 125 | 400 | 305 | 422 | ||||
| 150 | 440 | 358 | 485 | ||||
| 200 | 500 | 450 | 602 | ||||
| 250 | 580 | 503 | 710 | ||||
| 300 | 670 | 578 | 815 | ||||
| 350 | 780 | 598 | 844 | ||||
| 400 | 850 | 618 | 872 | ||||
| 450 | 850 | 693 | 978 | ||||
| 500 | 1000 | 765 | 1080 | ||||
